“Urea Steel 724L” is a trade name or manufacturer’s designation used in Europe (particularly by manufacturers like voestalpine, Sandvik, etc.) for a ultra-low carbon austenitic stainless steel used in urea high-pressure equipment. Its core purpose is to solve the severe corrosion problem posed by the urea synthesis medium (ammonium carbamate solution, high temperature and pressure).
Urea Steel 724L is a proprietary, ultra-low carbon austenitic stainless steel specifically engineered for urea synthesis service. It offers superior resistance to intergranular corrosion and uniform attack in the harsh ammonium carbamate environment.
Urea Steel 724L Characteristics & Design Purpose
Ultra-Low Carbon Content: The “L” stands for Low Carbon, typically C ≤ 0.020%, which is far below the 0.03% maximum for ordinary 304L/316L. This is to minimize the precipitation of chromium carbides at grain boundaries, thereby preventing intergranular corrosion after exposure to welding or sensitization temperatures (450-850°C) – one of the most critical corrosion forms in urea service.
Optimized Molybdenum Content: Typically in the range of 2.0 – 2.5%. Molybdenum significantly improves the material’s resistance to uniform corrosion and pitting corrosion in reducing media like urea synthesis solutions.
High-Purity Melting: Refined using processes like AOD and VOD, with strict control over impurity elements (e.g., S, P) and non-metallic inclusions to ensure microstructural homogeneity and corrosion resistance.
Отжиг раствора: Ensures complete dissolution of all carbides, resulting in a uniform austenitic microstructure.
724L Stainless Steel Equivalent Designations
“724L” is primarily a trade name/manufacturer’s designation. Its closest standardized equivalents are:
| Country/System | Стандарт | Эквивалентное обозначение | Примечания |
| Международный | УНС | S31050 | Closest unified numbering system code |
| Европа | EN / Werkstoff | (No direct 1:1 equivalent) | Often corresponds to a proprietary version of X2CrNiMo18-12 / 1.4435 with tighter controls |
| Manufacturer | Sandvik | 2RE69 | A well-known commercial equivalent |
| Япония | JIS | SUS 316L Mod (UG) | Under the broader “Urea Grade” category |
| Промышленность | Licensor Specs | Stamicarbon, Toyobo, Snamprogetti Grades | Defined by urea process licensors’ proprietary specifications |
Key Point: For procurement, the specification “Urea Grade 724L” or compliance with a specific licensor’s standard (e.g., Stamicarbon’s material specification) is more critical than a generic EN/ASTM code.
Chemical Composition (Typical / Specification Range)
The composition is optimized for maximum corrosion resistance in urea service.
| Элемент | Content (Weight %) | Purpose & Effect |
| Углерод | ≤ 0.020 (often ≤0.018) | Ultra-low to prevent sensitization & intergranular corrosion. |
| Хром | 17.0 – 18.5 | Provides basic passivity and oxidation resistance. |
| никель | 13.0 – 15.0 | Stabilizes austenite, improves toughness and overall corrosion resistance. |
| Молибден | 2.0 – 2.5 | Crucial for resistance to uniform corrosion in reducing urea medium. |
| Марганец | ≤ 2.0 | Austenite stabilizer, aids in deoxidation. |
| Кремний | ≤ 0.4 / 0.5 | Low level to avoid harmful sigma phase formation. |
| Азот | 0.10 – 0.16 | Strengthens austenite, improves pitting resistance. |
| Фосфор | ≤ 0.025 | Impurity, kept very low. |
| Сера | ≤ 0.010 | Impurity, kept very low for better corrosion resistance. |
| Железо | Баланс | Base. |
Special Requirements: Ferrite content is typically restricted (often <0.5%) to prevent selective corrosion. Material must pass the Huey Test (ASTM A262 Practice C) or similar corrosion tests per licensor requirements.
Механические свойства
| Свойство | Типичное значение | Condition / Note |
| Прочность на растяжение (Rm) | 500 – 650 MPa | Solution Annealed (1050-1150°C, water quenched) |
| Yield Strength (Rp0.2) | ≥ 200 MPa | |
| Удлинение (А5) | ≥ 40 % | Demonstrates excellent ductility. |
| Твёрдость | ≤ 220 HB | Typically Brinell hardness. |
| Ударная вязкость | > 100 J (at -196°C) | Excellent low-temperature toughness (Charpy V-notch). |
Примечание: For high-temperature design in urea reactors, creep strength и stress rupture data at ~180-210°C are critical and are provided in licensor data sheets.
Primary Application Areas
Urea 724L is used exclusively in the most critical sections of urea plants:
- Urea Synthesis Reactor (Converter): Wall lining plates и base material for strip overlay welding.
- High-Pressure Equipment: Carbamate condensers, decomposers, separators, and scrubbers.
- Critical Piping & Fittings: High-pressure piping, valves, and fittings in the synthesis loop.
- It is generally not used for non-critical or low-pressure parts downstream.
Common FAQs of Urea 724L
Three key differences: 1) Much lower carbon (≤0.020% vs. ≤0.030%), 2) Tighter control of impurities (S, P), and 3) Guaranteed performance in standardized corrosion tests (Huey test). Standard 316L would fail rapidly in a urea reactor.
Нет. Meeting the composition is necessary but not sufficient. Urea-grade steels require additional manufacturing process controls, heat treatment verifications, and mandatory corrosion testing certification as per licensor specs. A standard mill test certificate (MTC) for 316L is not acceptable.
The Huey Test (ASTM A262 Practice C) is an accelerated intergranular corrosion test where samples are boiled in 65% nitric acid for five 48-hour periods. It severely attacks sensitized grain boundaries. Urea-grade steels must show very low corrosion rates in this test to prove resistance to sensitization during welding or service.
Yes, but with strict procedures. It requires low heat input и proper filler metals (e.g., 724L filler or high-nickel alloys like 625 for overlay) to avoid sensitization in the heat-affected zone. Post-weld heat treatment is generally not required or recommended.
The primary failure mode is severe intergranular corrosion, leading to wall thinning, cracking, and potentially catastrophic leakage of high-pressure, toxic fluids. Uniform corrosion and stress corrosion cracking are also concerns.
