Reducing Flange

Reducing flanges are designed to connect pipes of different diameters, featuring a tapered inner hole that minimizes flow resistance for smooth fluid transfer. They are made from various materials, including carbon steel and stainless steel, ensuring adaptability to different environments and media. Easy to install and maintain, reducing flanges offer high strength to withstand high pressures and temperatures, making them widely used in industrial piping systems.

High Quality Reducing Flange

SSM produces reducing flanges designed to connect two sections of piping with different diameters. The inner hole of the reducing flange tapers from one end to the other, forming a conical or tapered structure. This design provides a sealed connection while allowing fluid to flow between different diameters, reducing flow resistance and potential pressure loss. Customers widely use these flanges in systems that require connecting different pipe sizes, such as in piping, piping systems, and equipment connections.

Types: Socket Weld Reducing Flange, Threaded Reducing Flange, Slip Reducing Flange, Weld Neck Reducing Flange, Reducing Blind Flange
Size: 1/2″ – 48″
Pressure: 150# – 1500#
Producing Standard: ASME B16.5, ASME B16.47 Series A & B, EN1092-1:2002, etc.
Materials: Carbon steel, Stainless steel, Monel, Hastelloy, Incoloy, Inconel, etc.

Features of Reducing Flange

Tapered Structure: The inner hole gradually reduces, forming a conical or tapered design that effectively connects pipes of different diameters.
Sealing Capability: Provides a reliable sealed connection, preventing leakage.
Flow Efficiency: Reduces flow resistance, decreases pressure loss, and enhances fluid transmission efficiency.
Easy Installation: Compatible with standard flanges, making installation and maintenance straightforward.

Carbon Steel Reducing Flange

Features: It offers strength and toughness and is suitable for medium to low-corrosion environments.
Applications: Widely used in oil, gas, and general industrial piping systems.
Surface Treatment: Typically galvanized or painted to enhance corrosion resistance.

Stainless Steel Reducing Flange

Features: Excellent corrosion resistance and oxidation resistance, suitable for harsh environments.
Applications: Commonly used in the chemical, food processing, and pharmaceutical industries.
Common Materials: 304 and 316 stainless steel are popular choices, providing varying levels of corrosion resistance.

Nickel Alloy Reducing Flange

Features: Exceptional corrosion resistance and high-temperature performance, suitable for extreme conditions.
Applications: Primarily used in aerospace, marine, and chemical industries, especially in high-temperature and high-pressure environments.
Common Materials: Examples include Inconel and Hastelloy, which are capable of withstanding extreme chemical and physical conditions.

Application of Reducing Flange

Piping Systems: Widely used in oil, chemical, pharmaceutical, and water treatment industries for piping systems.
HVAC Systems: Connect pipes of different diameters in heating, ventilation, and air conditioning systems.
Mechanical Equipment: Applied in fluid transport pipelines within mechanical equipment.

Advantages & Disadvantages of Reducing Flange

Advantages:

Efficient Connection: Effectively connects pipes of different diameters, providing flexibility for various applications.
Good Sealing Performance: Offers a reliable seal, reducing the risk of leakage.
Optimized Fluid Flow: The tapered design reduces flow resistance, lowers pressure loss, and enhances fluid transmission efficiency.
Easy Installation: Compatible with standard flanges, making installation and maintenance straightforward.

Disadvantages:

Higher Cost: Manufacturing costs may be higher compared to standard flanges.
Size Limitations: Specific models may restrict pipe diameter and pressure ratings, making them unsuitable for all applications.
Connection Strength: Under extreme pressure or temperature conditions, connection strength may be insufficient, requiring careful selection.

One-Stop Reducing Flange Provider for All Your Needs

SSM has significant product advantages in manufacturing Reducing Flange, Whether it’s quality or price, we will meet your needs.

More Information About Reducing Flange

What is a reducing flange?

A reducing flange is a type of flange used to connect pipes of different diameters. Its design allows a larger pipe to connect to a smaller pipe, facilitating the smooth transfer of fluids. Reducing flanges typically have a tapered inner hole to accommodate changes in pipe diameter and are commonly used in liquid or gas transportation systems.

FAQ About Reducing Flanges

How is a reducing flange installed?

Reducing flanges are typically installed using bolts to connect them to the corresponding flanges on the pipes. Proper alignment and sealing materials may be used to prevent leaks.

Are there different types of reducing flanges?

Yes, reducing flanges can be of various designs, such as weld neck, slip-on, and threaded types, depending on the piping system’s specific requirements.

Can reducing flanges be used in high-pressure applications?

Yes, reducing flanges are designed to withstand high pressures, but it’s essential to ensure that the selected flange is rated for your system’s specific pressure and temperature conditions.

How do I choose the right reducing flange?

When selecting a reducing flange, consider material compatibility, pressure, temperature ratings, and the specific dimensions needed for your application.

Why Can SSM Provide You with High-Quality Reducing Flanges?

SSM can provide high-quality Reducing Flanges due to its expertise, use of premium materials, advanced manufacturing processes, rigorous quality control, customization options, compliance with industry standards, customer-centric approach, and competitive pricing.
